offset printing machine 4 color, offset printing machine germany, computer bill printing machine

FOB Reference Price:Get Latest Price
1 Set/Sets computer bill printing machine (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Offset Printer
Condition:
New
Plate Type:
computer bill printing machine
Place of Origin:
Shanghai, China (Mainland)
Brand Name:
XSHEEN
Model Number:
XH470
Usage:
computer bill printing machine
Automatic Grade:
Automatic
Color & Page:
Multicolor
Voltage:
220V
Certification:
CE
After-sales Service Provided:
Overseas third-party support available
product name:
computer bill printing machine
warranty:
computer bill printing machine 1 year
Supply Ability
Supply Ability:
100 Set/Sets per Month computer bill printing machine
Packaging & Delivery
Packaging Details
computer bill printing machine packing in wooden carton
Port
shanghai
Lead Time :
within 5 workdays

XH470 perforating and binding machine, computer bill printing machine

Product Description

1. XH500DK, bill puncher/ folder machine, creaser folder

Features:

XH500DK Machine cast iron wall panels and machine base, frequency control, work stable, punching accuracy, hole plate lap 44 holes, according to the international standard production, enabling automatic punching, pressure horizontal, vertical broken line, folding and other processes.

Technical data:

Model

XH500DK

Max paper width:

533mm(20in”)

Max web diameter:

1000mm(40in”)

Punching diameter:

4+0.1mm

Paper quality

30-70g/m2

Folding length:

8in-15in

Working speed

8mpm to 100mpm

Power

1.5KW

Weight

1600KG

Machine size

3130(L)*1070(W)*1360(H)mm



2. Offset printers XH-470SPJ

Features:

XH470SPJ Bill printing machine adopt imported feeding tracks and advanced PLC system, touch screen operation, printing with high precision, high speed, up numbers printed can be realized, double colors printing with good quality.

Technical data:

Max paper width

470mm

Max printing area

454*345mm ( 7in-14in )

Tracking printing precision

<0.08mm

Printing speed

2000-10000 sheets/hour

Paper quality

30-170g/ m2

Power

1.5KW/220V/50HZ

Machine weight

670KG

Machine size

1750(L)*1050(W)*1550(H)mm





3.numbering machine XHDM720



Features of numbering machine:

1. Lateral and Vertical Perforation can be done at the same time;

2. Perfect Numbering Position & Legible Print with resin plate printing;

3. Numbering Speed up to 8,000 sheets per hour;

4. LCD computer controlling system is optional

5. Brand Parts: France Components (Schneider) & Japanese Bearings (NHK);

6. Oil Free Vacuum Pump adopts Japanese Technology;

7. Positive Limitation Protection is adopted to make sure safe operation;

8. Automatic Powdering & Blower system;

9. High quality Feeding Rubber-tired & Double Sheets Detection Device;

10. Chrome plated Technology and Stainless Steel Material are used to protect the roller

 Technical Data

Max. Paper Size

720x440mm

Min. Paper Size

180x150mm

Paper Weight

28-250g

Printing Speed

2000-8000 sheet/hour

Ink Roller

6 rollers(ink form rollers: 2pcs)

Number capacity:

Lateral: 7 row x 10 column=70

Vertical: 5 row x 12 column=60

Perforation

Min. space between Lateral Perforating knives: 30mm

Min. space between Vertical Perforating knives: 25mm

Power for main motor

1.5KW

Power for pump motor

1.5KW

Power Supply

220V 50HZ

Dimensions

2060x1170x1120mm

Weight

800kg




4. Bill binding machineXH-450

Features:

Imported PLC programmable controller, imported frequency conversion stepless speed regulation, and optoelectronic feed detection, automatic drawing code, coding, photoelectric control permits automatic decline, paper automatic lifting equipment, pre-style counter, with pages, play yards, claws set, cut in one, complete functions and easy operation

Technical data:

Application scope

Various types of computer paper, carbonless paper

Max paper width

450mm

Max layer rate

6 layers

Max numbering machine

42

Min numbering machine

1

Hole diameter

4+0.1 mm

Working speed

30-100/min

Power

0.75KW/220V

Machine weight

800KG

Machine size

3600(L)*940(W)*1100(H)mm
